Features
Broad, continuous tuning range from 700-1000 nm using a single optics set with custom wavelength ranges available < 700 nm or > 1000 nm
Ultra-narrow linewidths from < 50 kHz absolute linewidth, with options to achieve Hertz level linewidth via an external, ultra stable reference
Option to fit intra-cavity EOM for increased feedback bandwidth
Output power levels up to 6 W with high powers of > 2.5 W in SHG
Ultra stable output with relative intensity noise 0.075 % RMS with excpetional stability on longer timescales
Materials minimise effects from vibrations and thermal variations, resulting in a stable, low-frequency drift laser
Anti-humidity system and purge ports for trouble free operation across atmospheric absorptions
Continuous, single mode, high-resolution scans over >25 GHz, up to 300 nm (with TeraScan option)
Fully automated with wavelength tuning and locking via a web interface or published set of TCP/IP controls
Integrated extension modules available to extend the tuning range from 210 nm to 4000 nm
Beam pick off and fiber launch modules available/h5>
Most compact laser in its class
Applications
Atom/Ion Trapping and Cooling
High-Resolution Spectroscopy
Squeezed Light
Quantum Optics
2D Materials
Colour Centres
Quantum Dots
Microresonators
Specifications
| Model | Power (W) | ||||
|---|---|---|---|---|---|
| SolsTiS 5000 | > 5.0 | ||||
| SolsTiS 4000 | > 4.0 | ||||
| SolsTiS 3000 | > 3.0 | ||||
| SolsTiS 2000 | > 2.0 | ||||
| SolsTiS 1600 | > 1.6 | ||||
| SolsTiS 500 | > 0.5 | ||||
| Tuning Range (a) (nm) | -XS | -R | -F | -XF | -XL |
| SolsTiS 5000 | 725-875 | 725-960 | 850-1050 | ||
| SolsTiS 4000 | 670-710 | 725-875 | 725-975 | 700-1000 | 850-1050 |
| SolsTiS 2000 and 3000 | 725-875 | 725-975 | 700-1000 | 850-1030 | |
| SolsTiS 2000 | 725-875 | 725-975 | 700-1000 | ||
| SolsTiS 1600 | 725-875 | 725-975 | 700-1000 | ||
| SolsTiS 500 | 725-875 | 725-975 | |||
| Linewidth (b) | |||||
|---|---|---|---|---|---|
| SolsTiS SRX (Scanning Reference Cavity) (c) | < 50 kHz (reference cavity not shown) | ||||
| SolsTiS PSX (Passive Laser Resonator) | < 100 kHz | ||||
| SolsTiS LX (Etalon Lock) | < 5 MHz | ||||
| SolsTiS PX (Passive Etalon) | < 5 MHz | ||||
| SolsTiS BRF (BRF Only) | < 20 GHz | ||||
| Scan Range (d) | > 25 GHz, measured at ~ 780 nm, TeraScan option available | ||||
|---|---|---|---|---|---|
| Amplitude Noise | < 0.075% RMS including pump noise, added in quadrature (10 Hz - 10 MHz) | ||||
| Spatial Mode | TEM00 (M2 < 1.1) | ||||
| Beam Radius | < 0.4 mm, 1/e² intensity (nominal, at output port) | ||||
| Beam Divergence | < 1.5 mrad, far field, half angle | ||||
| Polarisation | Horizontal (pump and output beam) | ||||
| Laser Head Dimensions (e) | 243.2 x 142 x 88 mm (L x W x H) 9.57 x 6.8 x 3.5 inches |
||||
| Ice Bloc Controller Dimensions | 340 mm x Half Rack x 2U (L x W x H) | ||||
| AC Power | 90 - 264 VAC, 2.5 A maximum | ||||
| Cooling | Supplied closed-loop water chiller | ||||
| Environmental Requirements | Operating temperature range: 16-30°°C Maximum relative humidity: 80% non-condensing, up to 30°C |
||||
| Laboratory | Mounting surface: optical table Air free of dust (laminar air flow box recommended) |
||||
(a) Other custom tuning ranges are available-please enquire for specific wavelengths.
(b) RMS values. Unless otherwise stated, linewidth specification refers to an absolute linewidth measured over a period of 100 us.
(c) RMS values. Linewidth specification applies relative to reference cavity and also absolute linewidth. Relative linewidth measured indefinitely and absolute linewidth measured over a period of 100 us.
(d) SRX and PSX models only. Typical 25 GHz scan <0.15 seconds. TeraScan option for narrow linewidth scan full wavelength range.
(e) Laser head only. Excludes reference cavity. Excludes pump optics module, baseplate used with integrated pump lasers, or riser blocks in configuration using separate pump.
