Features
Flash lamp pumped picosecond amplifiers
Pulse energies up to 2.2 J
20 – 300 ps pulse duration
10 Hz pulse repetition rate
Diode pumped regenerative amplifier
Internal or external seeding source
Advanced beam shaping for high pulse energy
Thermally induced birefringence compensated design
Less than 10 ps RMS jitter synchronization pulses for streak camera triggering
Control through USB and LAN interfaces with supplied Windows control software (RS232 optional)
Vacuum image relay system
Optional temperature stabilized second, third and fourth harmonic generators
Optional extremely precise synchronization to external RF signal with PLL option
Optional Gaussian like spatial beam profile with Gaussian fit > 85% in near field
Optional reduced pulse duration to 20 ps
Applications
Time resolved spectroscopy
SFG/SHG spectroscopy
Nonlinear spectroscopy
OPCPA pumping
OPG/OPA pumping
Remote laser sensing
Satellite ranging
Other spectroscopic and nonlinear optics applications...
