Features
Up to 3.7 J at 1064 nm output pulse energy
Up to 1 kHz repetition rate
Multi-channel version 2 J per channel at 1064 nm
Pulse durations from 2 ns to 500 ns
Spatial Super-Gaussian beam profile
Low maintenance cost and long diode lifetime
Variable pulse duration and temporal pulse shape control (AWG) option available
Various customization possibilities to tailor for specific application
High efficiency diode pumping chambers
Small laser head footprint and OEM integration upon request
Internal system diagnostics
Thermally induced birefringence compensation for high pulse repetition rates
Integrated vacuum system for image translation for smooth Super-Gaussian beam profile
Burst version available
Optional thermally stabilized second and third harmonics generators
Optional industrial grade, portable laser housing with integrated power supplies and cooling units
Applications
Thomson Scattering
Multi-stage OPCPA pumping
Non-linear optics
Ti:S pumping
