Features
Up to 80 J from a single channel
Pulse durations from 100 ps to 20 ns
Spatial Super-Gaussian beam profile
Front-end options:
–Diode pumped single-mode (SLM) or multi-mode (MM) master oscillator featuring excellent stability, long lifetime and maintenance-free operation based on Nd:Glass or Nd:YLF.
–Temporally shaped seeder / regenerative amplifier configuration allowing application of smoothing technics.
–Wave front correction system based on deformable mirror (DFM).
Flash lamp / LD pumped pre-amplifier
Up to Ø60 mm aperture Nd:Glass power amplifiers
Laser protection by Faraday isolators preventing damage of laser rods by back-reflected light
Optimized design for maximum pulse energy extraction
Separately controlled PFN circuits for each flash lamp
Diagnostics and monitoring of system status based on microprocessor controller
Software guide for step-by-step performance check at designated control points
Optional second and third harmonics generators
Applications
OPCPA pumping
Thomson Scattering
Multi-stage OPCPA pumping
Non-linear optics
Ti:S pumping
Plasma and shock physics
