Features
High Stability
Low Amplitude and Phase Noise
All-PM Solution
Single Mode-Lock State
Menlo figure 9® Technology, Laser Output in Less than 60 Seconds
Repetition Rate 50-100 MHz
Smallest Footprint, No additional laser driver required
Applications
Amplifier seeding
Terahertz generation & terahertz physics
2-Photon polymerization and 3D printing
Ultrafast Spectroscopy
Multi-Photon Excitation
Specifications
| Item | ELMO 780 | ELMO 780 High Power |
|---|---|---|
| Central Wavelength | 780 nm ±10 nm | 780 nm ±10 nm |
| Average Power | > 75 mW (typ. 85 mW) | > 140 mW (typ. 165 mW) |
| Pulse Width | < 100 fs (typ. 85 fs) | |
| Output Port | free space | |
| Polarization | linear, p-polarized ** | |
| Dispersion Management | pigtailed and versatile SHG module with up to 0.5 m optical fiber supply * | |
| Repetition Rate * | 100 MHz (50-100 MHz with VARIO) | |
| Output Port at 1560 nm *** Switchable 780 nm/1560 nm |
fiber coupled, 1560 nm, >180 mW (typ. 210 mW), < 70 fs (typ. 50 fs) after up to 0.8 m detachable polarization maintaining patch cord |
|
| 2nd Fiber-Coupled Seed Port | yes | |
| 2nd High Power Output Port | available with MULTIBRANCH | |
* Please inquire for your specific combinations of average power, pulse duration and repetition rate.
** The versatile handheld SHG module can also be mounted in s-polarized orientation.
*** Output wavelength changeable from 780 nm to 1560 nm with additional patch cord.
