LASERMARK Series
Fast, Reliable, Permanent
LightMachinery's' LaserMark 950 and 960 series lasers provide a fast, reliable means of applying high quality permanent marks such as date and batch codes to consumer product packages and electronic components. These pulsed CO2 lasers complete the entire marking process in less than 1 micro-second so marking can be done ""on the fly"" without mark smearing or degradation that can occur in other types of laser marking.
Specifications
| Model | 950 | 960 |
|---|---|---|
| Sealing Standard | IEC 529 (IP66), NEMA 4 | NEMA 12 |
| High Voltage Switch | SSM - Solid State Modulator | |
| Electrical Standards | IEC 204:EN 60204 | |
| Weight | 188kg (414lbs) with remote | 181kg (398lbs) with remote |
| Laser Gas Mix | LaserMark 5 commercial laser premix | |
| Electrical Ppower | 50/600Hz, 2.0kVA single phase | |
| Voltage Options | 110V, 115V, 230V, 240V | |
| EMI | EN50081-2; EN50082-1; FCC Part 15, Subpart Class A | |
| Water Cooling | 90 litres (24 US gal) per hour at 10-25C (50-77F) | |
| RS-484 Interface | YES | |
| Internal Gas Bottle Option | YES | No |
