Features
Available Standard for Ø430 µm Coatings
50 mm Maximum Recoat Length
Compatible with High-Index Recoat Material
Ideal for Medium- to High-Volume Manufacturing
Specifications
| Fiber Recoaters with UV Curing LEDs | PTR305 |
|---|---|
| Recoater Type | Automatic |
| Recoater Mold | Pneumatic Split Quartz Plates (a) |
| Recoat Diameter (b) | 430 µm |
| UV Curing Source | 32 UV LEDs |
| Maximum Recoat Length | 50 mm |
| Recoat Material | High-Index UV Curable Acrylate |
| Recoat Injection | Automatic |
| Recoat Volume | Programmable (µL) |
| Recoat Injection Rate | Programmable (≤1.8 µL/s) |
| Cure Time (c) | 17 s (Typical) |
| Mold Cleaning Requirement (d) | At Start Up and Shut Down (e) |
| Total Cycle Time | 45 s (Typical) |
| Dimensions (L x W x H) | 10.14" × 5.77" × 6.50" (257.6 mm × 146.7 mm × 165.1 mm) |
| AC Power | 110 - 120 V / 200 - 240 V, 47-63 Hz |
(a) Requires an 80 - 120 psi Dry Compressed Air Source.
(b) Custom sizes available.
(c) Programmable via Controller; Mold Size and Recoat Material Dependent.
(d) The mold should be cleaned with either acetone or isopropyl alcohol, applied with a cotton swab. If the mold has an accumulation of cured material stuck on the plates, allow the cleaning solution (preferably acetone) about 60 - 90 seconds to soften and lift the material from the surface.
(e) The mold assembly should be cleaned before the first recoating process of the day and then again after the last recoating process of the day.
