Features
High Stability
Low Amplitude and Phase Noise
All-PM Solution
Single Mode-Lock State
figure 9® Technology, Laser Output in Less than 60 Seconds
Repetition Rate 30-100 MHz
Compact Laser Head and Silent Operation
Robust Design for Harsh Environments
Applications
Laser micromachining
Ultrafast Spectroscopy
Specifications
| Item | YLMO |
|---|---|
| Central Wavelength | 1045 nm ±10 nm |
| Average Power | > 4 W (@100 MHz) |
| Pulse Energy | > 40 nJ |
| Pulse Width | < 80 fs |
| Repetition Rate | factory set between 30 MHz and 100 MHz, ± 1 MHz |
| Output Port | free space |
| Polarization | p-pol. in free space (PER: typ. 23 dB) |
| Pulse Picking Option (only for 50 MHz or lower) | Realized by integrated fast AOM: Mode 1: Divides repetition rate by factor 3 or higher, pulse energy stays constant. Mode 2: Can be used as fast amplitude modulator. |
