Jasper X0

Industrial Femtosecond Laser

Application :

Laser Micro Drilling Laser Micro Cutting & Dicing

INQUIRE CATALOG DOWNLOAD

Model	Jasper X0-10	Jasper X0-20	Jasper X0-30	Jasper X0-60
Maximum average power	10 W	20 W	30 W	60 W
Maximum pulse energy	50 μJ	100 μJ	200 μJ	200 μJ
... at repetition rate up to	200 kHz	200 kHz	150 kHz	300 kHz
System base repetition rate	20 ± 2Mhz	20 ± 2Mhz	20 ± 2Mhz	20 ± 2Mhz
Repetition rate tuning	Selectable with control software
Internal	200 kHz - 20 MHz	200 kHz - 20 MHz	150 kHz - 20 MHz	300 kHz - 20 MHz
Pulse picker	Single Pulse - 2 MHz	Single Pulse - 2 MHz	Single Pulse - 2 MHz	Single Pulse - 2 MHz
Pulse duration	< 270 fs FWHM (< 250 fs typical)
Pulse duration tuning	< 270 fs - 8 ps (< 270 fs - 20 ps optional)
Central wavelength	1030 ± 5 nm
Optional wavelength outputs	With Harmonic Generation module (HGM): 515 nm,343 nm, 258 nm (available upon request)
Built-in pulse picker	Pulse on demand, any division of the base repetion rate
Beam quality M²	< 1.2 (~ 1.1 typical)
Output beam diameter 1/e²	2.5 ± 0.5 mm (other available upon request)
Polarization	Linear, vertical
Burst mode for process enhancement	Included
External gating trigger	Included
Laser control software	Included

*All specifications are subject to change without prior notice due to continuous improvements.
